Reinforcement Learning: Model-free Monte Carlo Learner

Up until now, whether we were running Policy Iteration, Value Iteration, or even model-based ADP, our drone always looked at the value of states to make decisions.

Under policy $\pi$, the value of state $s$ satisfies:

For the optimal policy:

Since both formulas require knowing $p(s' \mid s,a)$, they depend on having a model of the environment. To avoid this requirement, we can instead assign values to state–action pairs.

In the model-based setting, we look at the state value $v(s)$ and evaluate different actions by examining the successor states they tend to reach.

For example, from state 9 in Grid City:

• action UP might usually lead to state 5,
• action RIGHT might often drift into the building at state 10.

If we know the utilities of states 5 and 10, we can compare the actions. This requires knowing all successor states and the distribution over them. But in a model-free setting, we do not know where each action leads, nor with what probability because we don’t have access to transitoin model. So instead of valuing states, we value the action taken in the state:

Suppose the drone is in state 13. It has two possible actions:

• RIGHT → often moves toward 14, eventually reaching the goal
• UP → tends to drift back into state 9, forming inefficient loops

If the drone estimates:

then even without knowing any transition probabilities, the better action is clearly RIGHT.

This shift from valuing states to valuing state–action pairs is the key idea behind model-free Monte Carlo learning.

Estimating Q-values using the Monte Carlo approach

Each time the drone flies through Grid City, the only information the agent truly observes is the sequence:

Every episode of Grid City gives us exactly one such trajectory. Suppose an episode lasts $n$ steps. Then we observe:

• a sequence of states:

  $$[s_{t=1}, s_{t=2}, \ldots, s_{t=n}]$$

• a sequence of actions:

  $$[a_{t=1}, a_{t=2}, \ldots, a_{t=n}]$$

• a sequence of rewards:

  $$[r_{t=1}, r_{t=2}, \ldots, r_{t=n}]$$

From this, we also obtain a sequence of state-action pairs:

For each state-action pair, we can evaluate its outcome by summing all the rewards after that pair occurs. For example:

Similarly,

More generally, for the pair $(s_i, a_i)$:

This $G(s_i,a_i)$ is the sample return for that state-action pair in this episode. If we play many episodes, we will encounter the same pair $(s,a)$ multiple times. Each occurrence gives one sample return:

By the Monte Carlo principle, the expected return is simply the average of these samples:

Thus, without knowing $p(s'|s,a)$ or building a transition model, we can estimate Q-values directly from experience.

First visit vs every visit

Once the drone starts estimating Q-values by averaging returns, another question naturally arises:

“If I visit the same state–action pair multiple times in a single flight, which of those visits should I learn from?”

Imagine a long, windy episode:

State 13, Action RIGHT → later return = +0.52
State 13, Action RIGHT → later return = +0.41
State 13, Action RIGHT → later return = +0.47

All three happened in one episode. Should the drone treat all three returns equally?

Monte Carlo learning gives us two choices:

First-visit MC

In first-visit Monte Carlo, we only consider the first time a particular pair $(s,a)$ appears in an episode. Any later occurrences of the same pair are ignored for that episode.

Suppose in a single episode we observe:

The pair $(s_1, a_3)$ appears twice. Under first-visit MC, we take only the first occurrence and compute:

This value is appended once to the list $R(s_1, a_3)$.

Every-visit MC

In every-visit Monte Carlo, we use all occurrences of the pair within the episode. Each occurrence contributes its own return sample.

Using the same episode, we would add:

Both values are appended to the list $R(s_1,a_3)$.

Which one is better?

Both converge to the correct Q-values as long as the drone keeps exploring.

• First-Visit MC → more conservative, lower variance
• Every-Visit MC → uses more data per episode, faster but noisier

In practice, both work well. Both approaches converge to the same expectation:

And for our Grid City drone, the difference is subtle. it just needs to choose whether to learn a little cautiously or a little aggressively. In below algorithm we are considering first-visit MC.

$\textbf{Algorithm: Model-free MC learner percept} \\[6pt] \textbf{input: } \begin{cases} \text{previous state } s \\ \text{previous action } a \\ \text{reward } r \\ \text{current state } s' \end{cases} \\[10pt] \textbf{persistent: } \begin{cases} G(s,a)\ \text{estimate of state--action returns, initially zero} \\ \text{visited}(s,a)\ \text{initially false} \end{cases} \\[14pt] 1.\hspace{0.5cm} \textbf{if } \text{visited}(s,a) = \text{false then} \\[4pt] 2.\hspace{1.2cm} \text{visited}(s,a) \leftarrow \text{true} \\[10pt] 3.\hspace{0.5cm} \textbf{for each } \hat{s} \in S\ \textbf{do} \\[4pt] 4.\hspace{1.2cm} \textbf{for each } \hat{a} \in A\ \textbf{do} \\[4pt] 5.\hspace{1.8cm} \textbf{if } \text{visited}(\hat{s},\hat{a}) = \text{true then} \\[4pt] 6.\hspace{2.6cm} G(\hat{s},\hat{a}) \leftarrow G(\hat{s},\hat{a}) + r$

In actuate function, we apply the same geometric decay as in model-based ADP learner to control the transition from exploration to exploitation.

$\textbf{Algorithm: Model-free MC learner Actuate (Exploration--Exploitation)} \\[10pt] \textbf{Input: } \text{state } s \\[6pt] \textbf{Persistent: } \begin{cases} \pi(s) \text{ (current policy, initially random)} \\ \varepsilon \text{ (exploration probability, initially } 1.0) \end{cases}\\[12pt] 1.\hspace{0.5cm} \beta \leftarrow \text{random number in }[0,1] \\[6pt] 2.\hspace{0.5cm} \textbf{if } \beta < \varepsilon \ \textbf{then} \\[6pt] 3.\hspace{1.2cm} a \leftarrow \text{random action from } A \\[6pt] 4.\hspace{0.5cm} \textbf{else} \\[6pt] 5.\hspace{1.2cm} a \leftarrow \pi(s) \\[6pt] 6.\hspace{0.5cm} \text{return } a$

Updating the Policy After Each Episode

Monte Carlo learning is episodic. That means the drone must complete an entire journey through Grid City before it updates anything. After the drone finishes an episode, it gathers a return $G(s,a)$ for each state-action pair that was visited.

Now the question becomes:

How do we merge this new return into the existing estimate $Q(s,a)$?

The simplest and most statistically grounded method is to treat Q as the sample average of all observed returns:

But computing this directly means storing all past returns. We don’t want that.

So we use the incremental mean update, which avoids storing any history (We already derived this equation in multi-armed bandits blog):

$\textbf{Algorithm: Model-free MC learner policy update} \\[6pt] \textbf{persistent: } \begin{cases} \pi(s)\ \text{current policy} \\ G(s,a)\ \text{cumulative returns collected this episode} \\ Q(s,a)\ \text{current Q-value estimates} \\ \text{visited}(s,a)\ \text{boolean indicating first-visit} \\ N(s,a)\ \text{count of visits to each pair} \\ \varepsilon\ \text{exploration probability} \\ \xi\ \text{decay factor for } \varepsilon \end{cases} \\[12pt] 1.\hspace{0.5cm} \textbf{for each } \hat{s} \in S\ \textbf{do} \\[4pt] 2.\hspace{1.2cm} \textbf{for each } \hat{a} \in A\ \textbf{do} \\[4pt] 3.\hspace{1.8cm} \textbf{if } \text{visited}(\hat{s},\hat{a}) = \text{true then} \\[4pt] 4.\hspace{2.6cm} N(\hat{s},\hat{a}) \leftarrow N(\hat{s},\hat{a}) + 1 \\[8pt] 5.\hspace{2.6cm} Q(\hat{s},\hat{a}) \leftarrow Q(\hat{s},\hat{a}) + \frac{1}{N(\hat{s},\hat{a})} \big( \, G(\hat{s},\hat{a}) - Q(\hat{s},\hat{a}) \,\big) \\[10pt] 6.\hspace{0.5cm} \pi(\hat{s}) \leftarrow \arg\max_{a} Q(\hat{s},a) \\[12pt] 7.\hspace{0.5cm} \textbf{for each } \hat{s}\in S,\ \hat{a}\in A\ \textbf{do} \\[4pt] 8.\hspace{1.2cm} G(\hat{s},\hat{a}) \leftarrow 0 \\[4pt] 9.\hspace{1.2cm} \text{visited}(\hat{s},\hat{a}) \leftarrow \text{false} \\[10pt] 10.\hspace{0.5cm} \varepsilon \leftarrow \xi\, \varepsilon$

Here in above algorithm term $\pi(\hat{s}) \leftarrow \arg\max_{a} Q(\hat{s},a)$ is not very clear. will dicuss this in next section.

Connecting Q-values Back to State Values

Now that we’ve shifted focus from valuing states to valuing state–action pairs, a natural question appears:

What if we want the utility of a state again? Can we reconstruct it using Q-values alone?

Surprisingly, yes and it’s beautifully simple.

Imagine the drone is standing in state $s$. If it could choose any action, which one gives the greatest long-term return?

Exactly the action with the largest Q-value. So the optimal value of state $s$ is simply:

This equation says, the utility value of being in $s$ is equal to the value of taking the best possible action from $s$. No transition probabilities. No model. Just the best Q-value.

Recall the value-iteration optimality equation:

Here the reward $r(s)$ and discount factor $\gamma$ are constants. they don’t depend on $a$. Hence we can push the max outside:

Hence optimal Q-value:

Which is well aligned with the definition of the optimal Q value. This establishes the bridge between Q-values and state values. And once we know this, the optimal policy falls naturally out of the logic:

So that mysterious line in the policy update step:

…is just the drone choosing the action with the highest long-term payoff.

From value iteration we know that the optimal policy selects the action that yields the highest expected return:

 but because $r(s)$ and $\gamma$ are constant values which do not affect the function argmax, we can also write above equation like

Combining Everything Together

To train our learner, we use the following pseudo code to repeatedly play the game for N times, where N can be an arbitrarily large number. Each game of these N games can also be called an episode or an epoch.

$\textbf{Algorithm: Training MC learner for N episodes} \\[6pt] \textbf{input: } \begin{cases} \text{MDP black box} \\ \text{MC learner} \\ N\ \text{training episodes} \\ s_0\ \text{starting state} \\ S_{end}\ \text{set of terminal states} \end{cases} \\[12pt] 1.\hspace{0.5cm} \text{initialize } R \text{ with zeros} \\[4pt] 2.\hspace{0.5cm} \text{initialize } \text{ifwin with false} \\[10pt] 3.\hspace{0.5cm} \textbf{for } i \leftarrow 1 \text{ to } N\ \textbf{do} \\[4pt] 4.\hspace{1.2cm} s \leftarrow s_0 \\[10pt] 5.\hspace{1.2cm} \textbf{while } s \notin S_{end}\ \textbf{do} \\[4pt] 6.\hspace{2cm} a \leftarrow \text{MC learner actuate}(s) \\[4pt] 7.\hspace{2cm} r,\ s' \leftarrow \text{MDP black box}(s,a) \\[4pt] 8.\hspace{2cm} R(i) \leftarrow R(i) + r \\[4pt] 9.\hspace{2cm} \text{MC learner percept}(s,a,r,s') \\[4pt] 10.\hspace{2cm} s \leftarrow s' \\[10pt] 11.\hspace{1.2cm} \textbf{if } s \in S_{winning\_end}\ \textbf{then} \\[4pt] 12.\hspace{2cm} \text{ifwin}(i) \leftarrow \text{true} \\[10pt] 13.\hspace{1.2cm} \text{MC learner policy update} \\[10pt] 14.\hspace{0.5cm} \textbf{return } R,\ \text{ifwin}$

On-Policy Monte Carlo and Why We Need Something More

So far, our drone has been learning the way a child learns to ride a bike - by wobbling around, crashing a bit, and slowly improving based on its own experience. Everything we have discussed in this blog so far belongs to the family of on-policy Monte Carlo methods.

Why “on-policy”? Because the drone uses the same policy to generate experience and to improve itself. Look back at our actuate function:

• the drone chooses actions using the ε-greedy version of its current policy,
• then completes an entire episode following that policy,
• then uses the returns from that episode to update the same policy.
• then again drone chooses actions using the ε-greedy version of its updated policy

So the workflow is:

Although on-policy MC is simple and elegant. It requires executing the current (often poor and exploratory) policy to gather data. In the early stages, $\pi$ is terrible. On-policy learning makes perfect sense in theory. But in practice? It’s a bit scary. For a physical drone, this means lots of early crashes & bumping into buildings, wastes battery drifting around, and repeatedly spirals between states but because $\varepsilon$-greedy forces exploration, it must continue doing so even when human intuition/facts tells us those actions are awful.

On-policy MC insists:

You must try bad moves yourself in order to learn they are bad.

That’s costly. This motivates a key question:

Can we learn a good policy without letting the drone fly poorly in the early stages?

Or even:

Can we learn from flights that were generated by someone else, a human pilot, another drone, or a dataset?

This leads us to the natural next topic off-policy learning: how to learn from someone else’s experience.
